Fluid, Power and Signals into Anything That Turns
Deublin rotating unions carry water, steam, oil, air and coolant from a fixed pipe into turning machinery – rolls, drums, spindles and shafts. Norman G Clark is the exclusive Australian distributor of Deublin.
Not sure what you need? Call (03) 9116 9200 and talk it through with our team.
Solutions
What Do You Need to Get into the Turning Part?
Paper & tissue. Steam joints and siphons for dryer cans, water unions for calenders, and swivel joints.
Corrugating & packaging. High-pressure steam joints and siphons for corrugator rolls.
Steel & metals. Water unions for cooling rolls, casting and coil-winding unions, and hydraulics.
Machine tool. Through-spindle coolant unions, and clamping hydraulics through multi-passage unions.
Plastics, rubber & film. Heated and chilled rolls on calenders and film lines, and hydraulics.
Printing & converting. Chill rolls, heated rolls and air shafts.
Food & dairy. Steam-heated drum dryers and cookers, stainless water unions, and swivel joints.
Textile. Steam-heated drying cylinders and water unions.
Automotive. Machining spindles, clamping hydraulics and assembly automation.
Mining & drilling. Unions and washpipes for exploration and directional drilling rigs, and hydraulics on heavy plant.
Oil & gas. Top-drive washpipes, service kits, coiled tubing unions and slip rings.
Sugar milling. Steam and water unions for heated and cooled rolls and dryers.
Timber & panel products. Hot-oil heated presses – unions for the platens and swivel joints for the moving pipework.
Commercial laundry. Steam-heated ironers and dryers.
Wind energy. Slip rings and rotary unions for turbine pitch and yaw systems.
Semiconductor. Slip rings and multi-passage unions for wafer-handling machines.
Cool a Roll with Water
Carry water into a turning roll or drum – and back out – without a leak.
Heat a Roll with Steam or Hot Oil
Bring steam or hot oil into a heated roll, and take the condensate out.
Power Clamps and Clutches
Feed air or hydraulic oil to chucks, clamps, clutches and brakes as they turn.
Several Supplies, One Shaft
Keep oil, air, coolant and vacuum apart inside one union.
Coolant Through the Spindle
Feed coolant, oil mist or air through a machine tool spindle at high speed.
Let Pipework Move
Swivel joints let pipes turn and tilt with presses, arms and platens – safer than hose.
Keep the Rig Turning
Long-life washpipes, service kits and unions for drilling rigs.
Power and Signals Too
Slip rings pass electricity and data into turning machines – alone or with fluids.
The range
Deublin Products
Cool a roll with water
Water Unions
Water into turning rolls and drums, DN 10 to DN 125.
138 parts in the finder
Heat a roll with steam or hot oil
Steam & Hot Oil Unions
Steam and hot oil into heated rolls, with siphons to take the condensate out.
239 parts in the finder
Power clamps and clutches
Air & Hydraulic Unions
Air, vacuum and hydraulic oil to 400 bar, for clamps, chucks and clutches.
88 parts in the finder
Several supplies, one shaft
Multi-Passage Unions
Two to eight separate supplies through one union.
29 parts in the finder
Coolant through the spindle
Machine Tool Unions
Coolant, oil mist and air through spindles to 50,000 rpm.
127 parts in the finder
Let pipework move
Swivel Joints
Plane and self-aligning swivel joints for moving pipework.
See the range
Keep the rig turning
Drilling & Washpipes
Top-drive washpipes, seal kits and directional drilling unions.
See the range
Power and signals too
Slip Rings
Electrical power and signals into turning machines.
See the range
How they seal
Four Ways a Rotating Union Seals
Pressure Joints
Sealed by the pressure of the fluid, with a strong spring for start-up. Simple, but they take more effort to turn and suit only low pressures (under 17 bar).
Soft Seals
Polymer seals: compact, and good for slow or stop-start turning – but they wear and warm up faster.
Hydrostatic Seals
The turning part floats on a thin film of fluid, so nothing touches. Long life at high pressure, but limited to a few thousand rpm.
Mechanical Seals
Precisely flat, balanced seal faces: low wear, low heat, and they work above 140 bar and 40,000 rpm.
Why Deublin, through Norman G Clark
The World’s Largest Maker of Rotating Unions
Since 1945
Deublin has made rotating unions since 1945 and now makes over 500 standard unions in more than 3,000 models.
Made to Order Too
If a standard union won’t do, Deublin designs one for your machine.
Built to Be Rebuilt
Service kits and repair cartridges put worn unions back to work.
Local Advice
Norman G Clark is Deublin’s exclusive Australian distributor. Call (03) 9116 9200 for help choosing a union.
Literature
Catalogues
Catalogues
- General Industry catalogue (GI223-AU)
Water, steam, hot oil, air and hydraulic unions – Norman G Clark edition - Machine Tool catalogue (MT232-AU)
Spindle unions for coolant, MQL and air - Rotary unions & swivel joints (BC162)
Type C and CF steam unions, plane and self-aligning swivels
Industry Brochures
- Paper industry (PP232)
Rotating joints and siphon systems for paper machines - Corrugating (COR232)
Steam joint and siphon systems for corrugators - Steel industry (ST141)
Rotating unions for rolling and processing lines - Continuous casting (CC064)
Unions for continuous casting machines - Wind energy (WE232)
High pressure hydraulic unions for wind turbines
Fitting & Service
- Installation instructions
Fitting rotating unions and flexible hoses - Mechanical seal washpipe manual
Assembly guidance for users and OEMs
Talk to Us About Your Application
Tell us what the machine has to do – the load, the speed, how often it runs and the space you have – and we’ll help you choose the right Deublin product.
